CompactOne

CompactOne

The CompactOne is the smallest and lightest orbital welding-compact machine worldwide. Easy usability in smartphone-style, touch panel and several help functions make it to the innovation leader of the industry.

  • Welding process: TIG DC, constant or pulsed, with or without Oscillation, AVC and wire feeder
  • Input power: Single phase, 115/230 V ± 15% – 50/60 Hz
  • Main fuse: 16 A
  • Insulation class: H
  • Protection class: IP 23 S
  • Welding current: 3 to 220 A
  • Duty cycle (230V – 40°C): 100% – 160 A / 60% – 180 A / 40% – 220 A
  • Motor controls: Encoder and Tachospeed motors
  • Display / Recording: Welding current, Arc Voltage, electrode angular position, welding and wire speed
  • Connectivity (Documentation, Updates): 1 x RS232
  • Dimensions (L x W x H): 490 x 195 x 400 mm
  • Weight: 15,4 kg (without cooling unit)
  • Standard: EN 60974-1 / EN 60974-10
  • Article number: TiO-1006
Fact Sheet
